Operating angle

Approx. 20°

Operating force

15～27N

Mechanical life expectancy

5,000,000

Operating temperature

-30℃~+70℃

Storage temperature

-30℃~+70℃

Vibration

10~55Hz 98m/s²

Shock

294m/s²

Mass

Approx. 1100g

Protection degree

IP54

Standard resistance

10KΩ±20%, 5KΩ±20%

Effective electrical angle

Approx. 60°

Independent linearity tolerance

±3%

Resolution ratio

Essentially infinite

Power rating

0.25W

Output smoothness

<Against input voltage 0.2%

Contact resistance variation

<5%CRV

Insulation resistance

>1000MΩ (500V.D.C)

Dielectric strength

1 min (500V.A.C)

Color

Red，Black，White

Title

VCC，GND，OUT

Electrical specifications

POT. with other resistance(1K, 2K), special output characteristic, speical cable length, etc."

Other special specifications

With matching signal module
